Imprimante Code-Barre Xprinter XP-TT424B USB + LAN

Imprimante Code-Barre Xprinter XP-TT424B USB + LAN

Printing Features
Resolution: 203 DPI

Printing method: Thermal Transfer / Direct Thermal

Max.print speed: 127 mm (5”) / s Max.

Max.print width: 108 mm (4.25”)

Max.print length: 1778mm(70″)

Media
Media type: Continuous, gap, black mark, fan-fold and punched hole

Media width: 25.4-115 mm (1.0”-4.6”)

Media thickness: 0.06~0.18 mm

Media core diameter: 25.4 ~ 50.8 mm (1″ ~ 2″)

Ribbon length: Max.90m

Ribbon width: 25.4mm-110mm (1″-4.3″)

Label length: 10 mm ~1778 mm

Label roll capacity: 127 mm (5“) (External diameter)

Ribbon core inner diameter: 12.7 mm (0.5″)

Performance Features
Processor: 32-bit CPU

Memory: 8MB Flash Memory/ Flash memory can be expanded to Max. 4 GB

Interface: Standard: USB / LAN

Sensors: Gap sensor, Cover opening sensor, Black mark sensor, Ribbon sensor

Fonts/Graphics/Symbologies
Internal fonts: 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software.

1D bar code: Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13,EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST

2D bar code: PDF-417, Maxicode, DataMatrix, QR code

Rotation: 0°、90°、180°、270°

Emulaion: TSPL、EPL、ZPL、DPL

Physical Features
Dimension: 246mm*199mm*168mm (D*W*H)

Weight: 1.62kg

Reliability
Print head life: 30 km

Software
Driver: Windows/Linux/Mac

SDK: Windows/Android/iOS

Power supply
Input: AC 100-240V

Output: DC 24V, 2.5A

Options
Factory Options: Peeler, RTC

Dealer Options: External paper roll holder, Paper roll spindle, Extension board for external paper roll holder, Shipment waybill box

Environmental Conditions
Operation environment 5 ~ 40°C（41~104°F），Humidity: 25 ~ 85% non-condensing

Storage environment -40 ~ 60°C（-40~140°F），Humidity: 10 ~ 90% non-condensing
